Tooling Design & Engineering Services for Manufacturers

At Manor Tool & Manufacturing Company, we’ve been providing metal stamping services since 1959. We can handle production runs of any size and our 32-press facility enables us to run customer-provided dies or fabricate new tooling as needed. We can design and fabricate dies for stamping operations from sizes ranging from 44 inches wide and up to 92 inches in length, with press capacities up to 400 tons. Our portfolio includes a variety of value-added design and engineering services to support the needs of any customer project.

What Type of Tool Design and Engineering Services Can We Offer You?

No matter the complexity or scale of your project, our engineering team can support it with our extensive capabilities and support services. Our facilities are ISO 9001:2015-certified and our team of experts has years of experience providing design, prototyping, and re-design services. Our capabilities include:

  • Design consultations. Our engineers will explore the feasibility of your design to help identify any potential oversights or flaws.
  • Cost reduction and manufacturability analysis. Our team reviews your design to identify cost-saving opportunities and ensure that the design is compatible with known manufacturing processes.
  • Rapid prototyping and prototype development. Once the design phases is complete, we can rapidly generate a prototype and help you test it for functionality before moving on to full production.

We’re here to make sure your project goes smoothly. We will support your project from conception to final production and possess the capability to handle project volumes of any size. Our design capabilities include:

  • AutoCAD and Diemaker software. Our computer-aided design (CAD) software works concurrently with Diemaker to rapidly and effectively design metal stamping dies.
  • NX Progressive Die Wizard 7.5. Similarly, NX Progressive Die Wizard speeds up the design process by intelligently automating a number of tasks and enabling us to focus on creating the best final product.
  • Design assistance. Our advanced design software capabilities and experienced design engineers allow us to provide comprehensive design assistance throughout every step of your project.
  • Material selection. We will make recommendations for the materials best-suited to your design.
  • Prototype development. Utilizing our design software and Mastercam services, our engineering team can assist in developing prototypes for both low- and high-volume requests.
  • If your existing design is flawed or inefficient, we can redesign the part for maximum manufacturability.
  • Reverse engineering. If you don’t have access to the original design, we will conduct a thorough analysis of your existing part and work backwards to create a design for use in production.
  • We can help you design and fabricate simple or complex tooling for any project.

Manor Tool & Manufacturing + Mastercam

Manor Tool & Manufacturing Company uses Mastercam to assist all of our stamping, in-house tooling, machining, and secondary services. Mastercam is a comprehensive set of CAD tools that serve to expedite and simplify the design of complex parts. It is an incredibly useful resource for tool and die manufacturers, utilizing the latest industry technologies to drastically reduce occurrences of common production problems.

Mastercam utilizes Dynamic Motion to enable a faster cutting time, speeding up projects and reducing wear and tear on tooling. With its high attention to detail and ability to create quality surface finishes, Mastercam is the ideal tool for our engineering team to utilize as we work with you to design and produce your product.

Quality Metal Stamping at Manor Tool & Manufacturing

Whether you are seeking simple or complex metal stampings and tools, we combine our years of design and precision metal stamping experience to meet low or high volume production requirements. Manor will work with you every step of the way, providing exceptional service to match your specific tooling design and manufacturing design needs.

Scroll down to view our specifications. Please ​contact us for more information about any of our design, engineering, or metal stamping capabilities.

Manor Tool & Manufacturing Company uses MASTERCAM services to assist all of our stamping, in-house tooling, machining and secondary services. We can design and fabricate dies for stamping operations from sizes ranging from 44″ wide to 92″ long, and up to 400-ton press capacity. Along with new product development, Manor can assist in re-designing existing products with our reverse engineering services. This allows us to match the specific needs of your part or product with our full range of services.

Manufacturing design and tooling design services from our engineering team allow us to offer consulting services,
cost reduction analysis and manufacturability analysis. Our design engineering capabilities include AutoCAD with Diemaker, Unigraphics 7.5 NX Die Wizards, and a range of services such as design assistance, material selection consultation, and prototype development.

Whether you are seeking simple or complex metal stampings and tools, we combine our years of design and precision metal stamping experience to meet low or high volume production requirements. Manor will work with you every step of the way, providing exceptional service to match your specific tooling design and manufacturing design needs.

Contact Manor today and let us assist you in your next metal stamping design project.
